68RFE 4th Clutch Powerpack (2007-UP)

Dodge 68RFE Transmission 4th Clutch Powerpack

Made in the USA by Alto Products Corp

Contents

• (4) 128704A200 G3 Friction Plates
• (4) 128705-180 FNC Steel Plates
• (1) 128765A Stepped Pressure Plate

Directions

1. Install the 4C steel plates (1) and friction plates (2) starting with a steel plate and ending with a friction.
2. Install the stepped pressure plate (3) and snap ring.
3. Using air (40 PSI) apply the 2nd clutch several times to seat all of the clutch pack elements
4. Check clutch pack clearance using a feeler gauge in four places between the reaction plate and the snap ring. Clearance should be .040” to .050”
